| Purpose | roads and footpaths, outdoor areas, special |
| Benefits | LED module designed for direct replacement of inefficient conventional sources, without the need for structural modifications of the original luminaire |
| Model series | LED MOD RF G1 |
| Product name | LED Mod RF G1 |
| Luminous flux | 2920 lm |
| Luminous flux tolerance | ± 10 % |
| Luminous Efficacy of the luminaire | 133 lm/W |
| Correlated Colour Temperature (CCT) | 3000 K |
| Colour rendering index (CRI) | 70 Ra |
| Standard Deviation Colour Matching (SDCM) | 5 SDCM |
| Upward light output ratio (ULOR) | 0 |
| Ingress protection code | IP20 |
| Mounting method | integration into the original luminaire body |
| Nominal supply voltage | 230 V AC |
| Nominal supply frequency | 50 Hz |
| Nominal input power | 22 W |
| Class of protection | I |
| LED lifetime | 145000 (L90B50) hours |
| Power supply failure rate | ≤ 0,1 % / 1000 h |
| Environment | outdoor (exterior) |
| Minimum ambient temperature | -40 °C |
| Maximum ambient temperature | 35 °C |
| Luminaire ambient temperature (Tq) | 25 °C |
